Cisco 7609 User Manual

26-6
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 26 Configuring Port Security
Displaying Port Security Settings
To display traffic control information, enter one or more of these commands:
This example displays output from the show port-security command when you do not enter an interface:
Router# show port-security
Secure Port MaxSecureAddr CurrentAddr SecurityViolation Security
Action
(Count) (Count) (Count)
----------------------------------------------------------------------------
Fa5/1 11 11 0 Shutdown
Fa5/5 15 5 0 Restrict
Fa5/11 5 4 0 Protect
----------------------------------------------------------------------------
Total Addresses in System: 21
Max Addresses limit in System: 128
This example displays output from the show port-security command for a specified interface:
Router# show port-security interface fastethernet 5/1
Port Security: Enabled
Port status: SecureUp
Violation mode: Shutdown
Maximum MAC Addresses: 11
Total MAC Addresses: 11
Configured MAC Addresses: 3
Aging time: 20 mins
Aging type: Inactivity
SecureStatic address aging: Enabled
Security Violation count: 0
This example displays output from the show port-security address privileged EXEC command:
Router# show port-security address
Secure Mac Address Table
-------------------------------------------------------------------
Vlan Mac Address Type Ports Remaining Age
(mins)
---- ----------- ---- ----- -------------
1 0001.0001.0001 SecureDynamic Fa5/1 15 (I)
1 0001.0001.0002 SecureDynamic Fa5/1 15 (I)
1 0001.0001.1111 SecureConfigured Fa5/1 16 (I)
1 0001.0001.1112 SecureConfigured Fa5/1 -
1 0001.0001.1113 SecureConfigured Fa5/1 -
1 0005.0005.0001 SecureConfigured Fa5/5 23
1 0005.0005.0002 SecureConfigured Fa5/5 23
1 0005.0005.0003 SecureConfigured Fa5/5 23
1 0011.0011.0001 SecureConfigured Fa5/11 25 (I)
1 0011.0011.0002 SecureConfigured Fa5/11 25 (I)
-------------------------------------------------------------------
Total Addresses in System: 10
Max Addresses limit in System: 128
Command Purpose
Router# show port-security [interface interface_id]
Displays port security settings for the switch or for the
specified interface, including the maximum allowed number of
secure MAC addresses for each interface, the number of secure
MAC addresses on the interface, the number of security
violations that have occurred, and the violation mode.
Router# show port-security [interface interface_id]
address
Displays all secure MAC addresses configured on all switch
interfaces or on a specified interface with aging information
for each address.
