32-70
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 32 Configuring PFC QoS
Configuring PFC QoS
Configuring PFC QoS Statistics Data Export
Note Release 12.1(11b)E and later releases support PFC QoS statistics data export.
These sections describe how to configure PFC QoS statistics data export:
• Enabling PFC QoS Statistics Data Export Globally, page 32-70
• Enabling PFC QoS Statistics Data Export for a Port, page 32-71
• Enabling PFC QoS Statistics Data Export for a Named Aggregate Policer, page 32-72
• Enabling PFC QoS Statistics Data Export for a Class Map, page 32-73
• Setting the PFC QoS Statistics Data Export Time Interval, page 32-74
• Configuring PFC QoS Statistics Data Export Destination Host and UDP Port, page 32-75
• Setting the PFC QoS Statistics Data Export Field Delimiter, page 32-77
Enabling PFC QoS Statistics Data Export Globally
To enable PFC QoS statistics data export globally, perform this task:
This example shows how to enable PFC QoS statistics data export globally and verify the configuration:
Router# configure terminal
Router(config)# mls qos statistics-export
Router(config)# end
% Warning: Export destination not set.
% Use 'mls qos statistics-export destination' command to configure the export destination
Router# show mls qos statistics-export info
QoS Statistics Data Export Status and Configuration information
---------------------------------------------------------------
Export Status : enabled
Export Interval : 300 seconds
Export Delimiter : |
Export Destination : Not configured
Router#
Note You must enable PFC QoS statistics data export globally for other PFC QoS statistics data export
configuration to take effect.
Command Purpose
Step 1
Router(config)# mls qos statistics-export
Enables PFC QoS statistics data export globally.
Router(config)# no mls qos statistics-export
Disables PFC QoS statistics data export globally.
Step 2
Router(config)# end
Exits configuration mode.
Step 3
Router# show mls qos statistics-export info
Verifies the configuration.

Cisco 7609 Specifications

General

Chassis Slots	9
Switch Fabric Capacity	720 Gbps
Power Supply Options	AC or DC
Product Type	Router
Form Factor	Rack-mountable
Supported Line Cards	Various Cisco 7600 Series line cards
Operating System	Cisco IOS
Management	CLI, SNMP
Forwarding Performance	400 Mpps
Maximum Power Consumption	4000 Watts
Redundancy	Yes
Interfaces/Ports	Various, depending on line cards installed
