32-63
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 32 Configuring PFC QoS
Configuring PFC QoS
To map CoS values to tail-drop thresholds, perform this task:
When mapping CoS values to a tail-drop threshold, note the following:
• Use the transmit queue and threshold numbers.
• Queue 1 is the low-priority standard transmit queue.
• Queue 2 is the high-priority standard transmit queue.
• There are two thresholds in each queue.
• Enter up to 8 CoS values to map to the threshold.
This example shows how to map the CoS values 0 and 1 to standard transmit queue 1/threshold 1 for Fast
Ethernet port 5/36:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# interface fastethernet 5/36
Router(config-if)# wrr-queue cos-map 1 1 0 1
Router(config-if)# end
Router#
This example shows how to verify the configuration:
Router# show queueing interface fastethernet 5/36 | begin queue thresh cos-map
queue thresh cos-map
---------------------------------------
1 1 0 1
1 2 2 3
2 1 4 5
2 2 6 7
<...Output Truncated...>
Router#
Command Purpose
Step 1
Router(config)# interface type
1
slot/port
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Selects the interface to configure.
Step 2
Router(config-if)# wrr-queue cos-map
transmit_queue_# threshold_# cos1 [cos2 [cos3
[cos4 [cos5 [cos6 [cos7 [cos8]]]]]]]
Maps CoS values to a tail-drop threshold.
Step 3
Router(config-if)# no wrr-queue cos-map
Reverts to the default mapping.
Step 4
Router(config-if)# end
Exits configuration mode.
Step 5
Router# show queueing interface type
1
slot/port
Verifies the configuration.
