CONNECTING YOUR PHONE
Your system administrator will likely connect your new Cisco IP Phone to the corporate IP telephony network. If that is not the case,
refer to the graphic and table below to connect your phone.
DESCRIPTION
1 DC adaptor port (DC48V) for phones not provided with inline
2 AC-to-DC power supply
3 AC power cord
4 Network port (10/100 SW) for connecting to the network
5 Access port (10/100 PC) for connecting your phone to your
6 Handset port
7 Headset port
8 Footstand button

Cisco 7960 Specifications

General

Codecs	G.711, G.729a
Protocol Support	SCCP, SIP
Ethernet Ports	2 x 10/100 Ethernet ports
Power Options	Power over Ethernet (PoE), AC adapter
Audio	Full-duplex speakerphone
Buttons	6 line buttons
Weight	3.5 pounds
