Parameters for Configure Priorities for Voice and Video Data
The following table defines the function and usage of Configure Priorities for Voice and Video Data parameters
in the Network Settings section under the Ext(n) tab in the phone web interface. It also defines the syntax of
the string that is added in the phone configuration file with XML(cfg.xml) code to configure a parameter.
Table 31: Parameters for Moving Active Call to Locations
DescriptionParameter
Time of service (ToS)/differentiated services
(DiffServ) field value in UDP IP packets carrying a
SIP message.
Perform one of the following:
• In the phone configuration file with
XML(cfg.xml), enter a string in this format:
<SIP_TOS_DiffServ_Value_1_
ua="na">0x68</SIP_TOS_DiffServ_Value_1_>
• In the phone web page, enter the field value in
UDP IP packets carrying a SIP message.
Default: 0x68
SIP TOS/DiffServ Value
Value for the ToS field of voice data packets.
Sets the priority for voice packets in data traffic.
Perform one of the following:
• In the phone configuration file with
XML(cfg.xml), enter a string in this format:
<RTP_TOS_DiffServ_Value_1_
ua="na">0xb8</RTP_TOS_DiffServ_Value_1_>
• In the phone web page, enter the value for the
ToS field.
Default: 0xb8
RTP ToS/DiffServ Value
Value for the ToS field of video data packets.
Sets the priority for video packets in data traffic.
Perform one of the following:
• In the phone configuration file with
XML(cfg.xml), enter a string in this format:
<Video_RTP_TOS_DiffServ_Value_1_
ua="na">0x80</Video_RTP_TOS_DiffServ_Value_1_>
• In the phone web page, enter a valid value for
the ToS field of video data packets. .
Default:
Video RTP ToS/DiffServ Value
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
215
Cisco IP Phone Configuration
Parameters for Configure Priorities for Voice and Video Data
