The Cisco IP Phone 8811 does not support a key expansion module.

Note

Cisco IP Phones 8841 and 8845

The following section describe the attributes of the Cisco IP Phones 8841 and 8845.

Phone Connections

Connect your phone to the corporate IP telephony network, using the following diagram.

Access port (10/100/1000

PC) connection.

5DC adaptor port

(DC48V).

Auxiliary port.6AC-to-DC power supply

(optional).

Handset connection.7AC power wall plug

(optional).

Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later

Cisco IP Phone 8800 Series Multiplatform Phone Hardware

Cisco IP Phones 8841 and 8845
