Use DNS SRV for HTTP Provisioning
New phones use DNS SRV as one method of auto provisioning. For existing phones, if your network is set
up for provisioning with DNS SRV for HTTP, you can use this feature to resync your phone. Sample
configuration file:
<flat-profile>
<!-- System Configuration -->
<Primary_DNS ua="rw">10.89.68.150</Primary_DNS>
<Back_Light_Timer ua="rw">Always On</Back_Light_Timer>
<Peer_Firmware_Sharing ua="na">Yes</Peer_Firmware_Sharing>
<Profile_Authentication_Type ua="na">Basic Http Authentication </Profile_Authentication_Type>
<Proxy_1_ ua="na">example.com</Proxy_1_>
<Display_Name_1_ ua="na">4081001141</Display_Name_1_>
<User_ID_1_ ua="na">4081001141</User_ID_1_>
</flat-profile>
Procedure
Perform one of the following actions. Then, Set the Profile Rule with the SRV Option on the Web Page, on
page 29 or Set the Profile Rule with the SRV Option on the Phone, on page 29
• Place the XML configuration file, $PSN.xml, in the web server root directory.
• Place the XML configuration file, $MA.cfg, in the web server root directory/Cisco/.
Set the Profile Rule with the SRV Option on the Web Page
You can use the SRV option to download a configuration file to your phone.
Before you begin
Access the Phone Web Interface, on page 104
Procedure
Step 1 Select Voice > Provisioning
Step 2 In the Profile Rule field, enter the profile rule with the SRV option. Only HTTP and HTTPS are supported.
Example:
[--srv] https://example.com/$PSN.xml
Set the Profile Rule with the SRV Option on the Phone
You can use the SRV option on your phone to download a configuration file.
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
29
Cisco IP Phone Provisioning
Use DNS SRV for HTTP Provisioning
