CHAPTER 16
Corporate and Personal Directory Setup
• LDAP Configuration, on page 295
• Configure BroadSoft Settings, on page 302
• Set up Personal Directory, on page 306
• Enable Reverse Name Lookup, on page 307
LDAP Configuration
The Cisco IP Phone supports Lightweight Directory Access Protocol (LDAP) v3. LDAP Corporate Directory
Search allows a user to search a specified LDAP directory for a name, phone number, or both. LDAP-based
directories, such as Microsoft Active Directory 2003 and OpenLDAP-based databases, are supported.
Users access LDAP from the Directory menu on their IP phone. An LDAP search returns up to 20 records.
The instructions in this section assume that you have installed an LDAP server, such as OpenLDAP or
Microsoft Active Directory Server 2003.
Prepare the LDAP Corporate Directory Search
Before you begin
Access the phone administration web page. See Access the Phone Web Interface, on page 104.
Procedure
Step 1 Select Voice > System.
Step 2 In the IPv4 Settings section, enter the IP address of the DNS server in the Primary DNS field.
This step is required only if you are using Active Directory with authentication set to MD5.
You can configure this parameter in the configuration file by entering a string in this format:
<Primary_DNS ua="na">10.74.2.7</Primary_DNS>
Step 3 In the Optional Network Configuration section, in the Domain field, enter the LDAP domain.
This step is required only if you are using Active Directory with authentication set to MD5.
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
295
