DescriptionParameter
Enter a fully qualified domain name or IP address of an LDAP server.
Enter the host name of the LDAP server if the MD5 authentication method is used.
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<LDAP_Server ua="na">ldapserver.com</LDAP_Server>
• In the phone web interface, enter IP address or host name of the LDAP server.
Default: Empty
Server
Specify a starting point in the directory tree from which to search. Separate domain
components [dc] with a comma. For example:
dc=cv2bu,dc=com
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<LDAP_Search_Base ua="na">dc=cv2bu,dc=com</LDAP_Search_Base>
• In the phone web interface, enter the search base.
Default: Empty
Search Base
Enter the distinguished name domain components [dc]; for example:
dc=cv2bu,dc=com
If you are using the default Active Directory schema (Name(cn)->Users->Domain), an
example of the client DN follows:
cn=”David Lee”,dc=users,dc=cv2bu,dc=com
cn=”David Lee”,dc=cv2bu,dc=com
username@domain is the client DN format for a Windows server
For example, DavidLee@cv2bu.com
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<LDAP_Client_DN ua="na">dc=cv2bu,dc=com</LDAP_Client_DN>
• In the phone web interface, enter the client domain name.
Default: Empty
Client DN
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
297
Cisco IP Phone Configuration
Parameters for LDAP Directory
