Step 5 In the Webex directory settings screen, edit the name in the Directory name box. The name you enter
displays as the Webex directory name under Directory list.
Step 6 Click Save.
Search for a Contact in Your Webex Directory
You can search contacts in the Webex directory by email or name.
Before you begin
Your administrator enables the Webex directory.
Procedure
Step 1 Press Contacts.
Step 2 In the Directory screen, select the Webex directory.
By default, the directory name is Webex directory.
Step 3 In the Search Webex directory screen, enter the search criteria which is either a name or an email.
Step 4 Click Search.
You can also search a Webex contact from the All directory search screen by entering name or
email. For more information, see Search for a Webex Contact in All Directory, on page 54.
Note
The search operation sometime retrieves contacts with same name, work phone number, and mobile
number. In such cases, Webex directory displays only one contact and considers the remaining contacts
as duplicate.
For example:
If a search retrieves A (Name: "abc", Work phone: "123456") and B (Name: "abc", Work phone is
"123456"): Directory displays A only.
If a search retrieves A (Name: "abc", Work phone: "123456", and Mobile phone: "8888"), B (Name:
"abc", Work phone: "123456", and Mobile phone: "8888"): Directory displays A only.
If the search retrieves A (Name: "abc", Work phone: "123456", and Mobile phone: "8888"), B (Name:
"abc", Work phone: "123456", and Mobile phone: "2222"): Directory display both A and B.
Step 5 (Optional) Select a contact from the searched list and press Details. You see the details, such as name, work
phone number, mobile phone number, email, and department.
Step 6 (Optional) Select a contact and make a call.
If a contact has both work phone number and mobile phone number, the directory displays the work
phone number as the call number. Work phone number has higher priority than the mobile phone number.
From the details screen, if you select the name or the work phone number and make a call, the phone
dials the work phone number. But, if you select the mobile number and make a call, the phone dials the
mobile phone number.
If a contact has only mobile number, the directory displays the mobile phone number as the call number.
Cisco IP Conference Phone 8832 Multiplatform Phone User Guide
53
Contacts
Search for a Contact in Your Webex Directory

Table of Contents

Other manuals for Cisco 8832

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco 8832 and is the answer not in the manual?

Cisco 8832 Specifications

General IconGeneral
Control typeButtons
Display typeLCD
Product typeIP conference phone
Voice codecsG.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
CertificationCE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product colorCharcoal
Frequency range100 - 20000 Hz
Built-in displayYes
Display diagonal3.9 \
Languages supportARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution480 x 128 pixels
Security algorithmsEAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates10, 100 Mbit/s
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables includedUSB
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 95 %
Operating relative humidity (H-H)10 - 90 %
USB connector typeUSB Type-C
RJ-45 ports quantity1
Weight and Dimensions IconWeight and Dimensions
Width278 mm
Height61 mm
Weight1850 g
