Before you begin
Your administrator provides you the server address and port of the proxy server.
Procedure
Step 1 Press Settings.
Step 2 Select Network configuration > HTTP proxy settings > Proxy mode.
Step 3 Press the Select button of the navigation cluster to choose Manual.
Step 4 Enter a valid hostname or IP address of a proxy server in Proxy host.
Do not provide the scheme (http:// or https://) for the proxy host.
Note
Step 5 Enter a valid server port of the specified proxy server in Proxy port.
Step 6 (Optional) If your proxy server requires authentication, highlight Proxy authentication and then select On.
Step 7 (Optional) Enter your username and password to access the proxy server.
If you don't have the username and password, contact your administrator.
Step 8 Press Set to apply the settings.
Set Up a Proxy Server from the Phone Web Page
You can choose the auto or manual proxy mode to set up an HTTP proxy server from the phone web page.
Procedure
Step 1 On the phone web page, select Voice > System.
Step 2 Under the section HTTP Proxy Settings, set the parameters described in the following table:
Table 2: HTTP Proxy Settings
DescriptionParameter
Choose the proxy mode for the HTTP proxy setting.
Options are:
• Auto
• Manual
• Off
Default: Off
Proxy Mode
Cisco IP Conference Phone 8832 Multiplatform Phone User Guide
88
Settings
Set Up a Proxy Server from the Phone Web Page

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
