Cisco ASR 9010 Overview And Reference Guide

3-7
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Chapter 3 High Availability and Redundant Operation
Power Supply Redundancy
Figure 3-9 DC System Power Redundancy for the Cisco ASR 9006 Router Version—2
Figure 3-10 DC System Power Redundancy for the Cisco ASR 9904 Router—Version 2
Figure 3-11 DC System Power Redundancy for the Cisco ASR 9922 Router—Version 2
344092
2100W DC
2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
14,700W DC system
7+1 max power redundancy
2,100W DC system 1+1 min
power redundancy
2100W DC
2,100W DC system 1+1 min power
redundancy
6,300W DC system
3+1 max power redundancy
2100W DC 2100W DC 2100W DC 2100W DC 2100W DC
390185
344096
2100W DC 2100W DC 2100W DC 2100W DC 2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
6,300W DC system
3+1 min power redundancy
31,500W DC system
15+1 max power redundancy

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
