Chapter 2 Functional Description
Route Processor Card
Front Panel Connectors
This section describes the front panel ports and connectors of the RSP/RP card.
Management LAN Ports
Two dual-speed (100M/1000M) management LAN RJ-45 connectors are provided for use as out-of-band
management ports. The speed of the management LAN is autonegotiated.
Console Port
The EIA/TIA-232 RJ-45 Console Port provides a data circuit-terminating equipment (DCE) interface for
connecting a console terminal. This port defaults to 9600 Baud, 8 data, no parity, 2 stop bits with flow
control none.
Auxiliary Port
The EIA/TIA-232 RJ-45 auxiliary port provides a data circuit-terminating equipment (DCE) interface
that supports flow control. Use this port to connect a modem, a channel service unit (CSU), or other
optional equipment for Telnet management. This port defaults to 9600 Baud, 8 data, no parity, 1 stop bit
with software handshake.
Alarm Out
Alarm circuitry on the RSP/RP activates dry contact closures that are accessible through the nine-pin
Alarm Out connector on the RSP/RP front panel. Each RSP/RP card drives a set of three alarm output
contacts. Both normally-open and normally-closed contacts are available.
Only the active RSP/RP drives the alarm outputs. Should a switchover to the standby RSP/RP occur, the
newly active RSP/RP drives the alarm outputs.
Synchronization Ports
The SYNC 0 and SYNC 1 ports are timing ports that can be configured as Building Integrated Timing
System (BITS) ports. A BITS port provides a connection for an external synchronization source to
establish precise frequency control at multiple network nodes, if required for your application. The
RSP/RP card contains a Synchronous Equipment Timing Source (SETS) that can receive a frequency
reference from an external BITS timing interface or from a clock signal recovered from any incoming
1 SYNC (BITS/J.211) ports 8 External USB port
2 SFP/SFP+ ports 9 Management LAN ports
3 IEEE 1588 port 10 CONSOLE and AUX ports
4 Inter-chassis nv Sync0 11 Alarm Cutoff (ACO) and Lamp Test push buttons
5 Inter-chassis nv Sync1 GPS ToD 12 Nine discrete LED indicators
6 10 MHz and 1 PPS indicators 13 LED matrix display
7 Alarm Out DB9 connector

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
