Appendix A Technical Specifications
Table A-17 lists the AC input voltage range for the AC-powered Cisco ASR 9000 Series Routers
(single-phase power source).
Table A-18 lists the DC input voltage range for the DC-powered Cisco ASR 9000 Series Routers.
Table A-19 lists the DC output tolerances for AC or DC power modules for the version 1 power system.
Table A-17 AC Input Voltage Range
Range Minimum
Minimum
Nominal Nominal
Maximum
Nominal Maximum
Input Voltage 180 VAC 200 VAC 220 VAC 240 VAC 264 VAC
Line Frequency 47 Hz 50 Hz 50/60 Hz 60 Hz 63 Hz
Table A-18 DC Input Voltage Range
Range Minimum Nominal Maximum
Input Voltage –40 VDC –48 VDC –72 VDC
Table A-19 DC Output Levels for Version 1 Power System
Parameter Value
Voltage
Maximum –54.5 VDC
Nominal –54.0 VDC
Minimum –53.5 VDC
Power
Minimum (one power module) 1500 W
Maximum (three 2100 W power modules per tray x two
trays)
12,600 W (Cisco ASR 9010 Router only)
1
1. Maximum output power the power system is capable of supporting (not system power consumption).
Maximum (three 2100 W power modules in a single tray) 6300 W (Cisco ASR 9006 Router only)

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
