Fabric Controller Card
Figure 1-27 shows the FC card.
Figure 1-27 FC Card
Figure 1-28 shows the front panel of the FC card. The front panel has a status LED, ejector levers, ejector
lever release buttons, and mounting screws.
Figure 1-28 FC Card Front Panel
302403
302405
