Chapter 1 Overview and Physical Description
Rack-Mounting Considerations
Figure 1-10 Cisco ASR 9904 Router Chassis Footprint Dimensions—Top Down View
351294
Rear of chassis
Front of chassis
6.00 in
(15.24 cm)
2.45 in
(6.22 cm)
2.45 in
(6.22 cm)
2.282 in
(5.79 cm)
25.02 in
(63.54 cm)
17.57 in
(44.64 cm)
18.97 in
(48.19 cm)
6.00 in
(15.24 cm)
Rack
mounting
surface
