Cisco ASR 907 User Manual

SignalPinSignal NamePin Number
TX Tip Port 1144TX Ring Port 1112
TX Tip Port 1245TX Ring Port 1213
TX Tip Port 1346TX Ring Port 1314
TX Tip Port 1447TX Ring Port 1415
TX Tip Port 1548TX Ring Port 1516
TX Tip Port 1649TX Ring Port 1617
TX Tip Port 1750TX Ring Port 1718
TX Tip Port 1851TX Ring Port 1819
TX Tip Port 1952TX Ring Port 1920
TX Tip Port 2053TX Ring Port 2021
TX Tip Port 2154TX Ring Port 2122
TX Tip Port 2255TX Ring Port 2223
TX Tip Port 2356TX Ring Port 2324
Open57Open25
Open58Open26
Open59Open27
Open60Open28
Open61Open29
Open62Open30
Open63Open31
Open64Open32
Table 26: Port 24-47 TX
SignalPinSignal NamePin Number
TX Tip Port 2433TX Ring Port 241
TX Tip Port 2534TX Ring Port 252
TX Tip Port 2635TX Ring Port 263
TX Tip Port 2736TX Ring Port 274
Cisco ASR 907 Router Hardware Installation Guide
169
Troubleshooting
AMP64 Pinouts

Cisco ASR 907 Specifications
