Cisco ASR 907 User Manual

SignalPinSignal NamePin Number
TX Tip Port 2837TX Ring Port 285
TX Tip Port 2938TX Ring Port 296
TX Tip Port 3039TX Ring Port 307
TX Tip Port 3140TX Ring Port 318
TX Tip Port 3241TX Ring Port 329
TX Tip Port 3342TX Ring Port 3310
TX Tip Port 3443TX Ring Port 3411
TX Tip Port 3544TX Ring Port 3512
TX Tip Port 3645TX Ring Port 3613
TX Tip Port 3746TX Ring Port 3714
TX Tip Port 3847TX Ring Port 3815
TX Tip Port 3948TX Ring Port 3916
TX Tip Port 4049TX Ring Port 4017
TX Tip Port 4150TX Ring Port 4118
TX Tip Port 4251TX Ring Port 4219
TX Tip Port 4352TX Ring Port 4320
TX Tip Port 4453TX Ring Port 4421
TX Tip Port 4554TX Ring Port 4522
TX Tip Port 4655TX Ring Port 4623
TX Tip Port 4756TX Ring Port 4724
Open57Open25
Open58Open26
Open59Open27
Open60Open28
Open61Open29
Open62Open30
Open63Open31
Open64Open32
Cisco ASR 907 Router Hardware Installation Guide
170
Troubleshooting
AMP64 Pinouts

Cisco ASR 907 Specifications
