Cisco ASR 907 User Manual

• External management interfaces (RS232 console, management ENET, USB console, USB storage) and
system status LED indicators
Supported RSPs
Effective Cisco IOS-XE Release 3.16, the Cisco ASR 907 Router supports the following RSP:
• A900-RSP3C-400-W—Provides 8 GB of SDRAM, 20 Mb of TCAM memory on every ASIC.
The RSP does not provide external network interfaces for user traffic. All network interfaces are provided
through separate IMs.
Supported RSP Features
The RSP provides the following features on the Cisco router:
• Centralized data plane, timing, and control plane functions for the system
• High-level control of interface modules
• Management functionalities for the router
• Control plane (host) CPU and associated memory in which IOS-XE and platform control software runs
• Nonvolatile memory for storage of software images, configurations, and system files
• Enabling and monitoring the health and presence of fan trays, interface modules, and power supplies
• Field replacement and hot-swap capabilities
Swapping of Interface Modules
The following Ethernet interface modules support swapping on the Cisco A900-RSP3C-400-W module.
• 8-port Gigabit Ethernet SFP Interface Module (8X1GE)
• 8-port Gigabit Ethernet RJ45 (Copper) Interface Module (8X1GE)
• SFP Combo IM—8-port Gigabit Ethernet (8X1GE) + 1-port 10 Gigabit Ethernet (1X10GE)
• Copper Combo IM—8-port Gigabit Ethernet (8X1GE) + 1-port 10 Gigabit Ethernet Interface
Module(1X10GE)
• 2-port 10 Gigabit Ethernet Interface Module (2X10GE)
• 2-port 40 Gigabit Ethernet Interface Module (2X40GE)
• 1-port 100 Gigabit Ethernet Interface Module (1X100GE)
• 2-port 100 Gigabit Ethernet (QSFP) Interface Module (2X100GE)
• 1-Port OC-192 or 8-Port Low Rate CEM Interface Module
• 48 T1/E1 TDM Interface Module (48XT1/E1)
• 48 T3/E3 TDM Interface Module (48XT3/E3)
Use the hw-module subslot default command before performing a swap of the modules. to default the
interfaces on the interface module.
The hw-module subslot default command is not supported on the TDM and OC-3 interface modules.
Note
Cisco ASR 907 Router Hardware Installation Guide
8
Cisco ASR 907 Router Overview
Supported RSPs
