Cisco Catalyst IW9167I - Connectors and Ports

• 2.4 GHz IoT Bluetooth Low Energy (BLE) radio
• Integrated GNSS
• 1 x multi-Gigabit (mGig) copper Ethernet port (supporting PoE, including IEEE 802.3at/bt, Cisco UPoE,
100 Mbps/1 Gbps/2.5 Gbps/5 Gbps)
• 1 x SFP interface—Supports up to 10 Gbps
• Optional M12 adapter for network and power interfaces
• Dual power input options—PoE-in and 24 - 48VDC
• Dual mounting options—Pole or wall mount
• IP67 rating
• Indoor and outdoor mode operation supported in different countries as shown in the following table:
Indoor and outdoorFCC
OutdoorIC
Indoor and outdoorCE
OutdoorC-tick
OutdoorTelec
Connectors and Ports
The following figure shows the available ports on the AP front panel.
Figure 1: IW9167I Front Panel Connectors and Ports
