Step 3 Drill holes on the mounting surface for plastic wall anchors to suit 1/4-20 or M6 bolts, and add the appropriate anchors.
Step 4 Align the access point mounting holes with the drilled holes.
Step 5 Insert a mounting screw in each of the four mounting holes and tighten.
Step 6 You can use the keyholes for “hands-free” installation.
Ensure that the access point is firmly secured.
Note
Using the DIN Rail Mounting Bracket
You can use DIN rail mounting in network or electrical closets or cabinets, or in wiring rooms that have
low-levels of shock and vibration. The following figure shows the DIN rail and DIN rail mounting assembly.
