Pole mounting bracket3Access point1
Pole4M6 bolts and washers2
Ensure that the access point is firmly secured to the mounting bracket.
Note
Never leave the access point unattended if the mounting hardware is not torqued to full value.
Caution
Attaching a Power Adapter
If you want to attach a power adapter (IW-PWRADPT-MFIT4P=) to the access point on a pole using the
mounting bracket AIR-ACCPMK3700= or AIR-ACCPMK3700-2=, use the procedures in the following
sections.
Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700=
To attach a power adapter (IW-PWRADPT-MFIT4P=) to the access point on a pole using the mounting
bracket AIR-ACCPMK3700=, use the following procedures:
Step 1 Ensure you have the mounting bracket set up as described in Step 1 of Using the Mounting Bracket AIR-ACCPMK3700-2=,
on page 25.
Step 2 Attach the power supply using 4x 6-32 screws and torque the screws to 8.3-11 in-lbs, as shown in the following figure.
Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide
30
Installation Overview
Attaching a Power Adapter
