DC power port connected using cable gland3SFP port connected using cable gland1
RJ-45 port connected using cable gland2
Using M12 Adapter on SFP Port
M12 adapter can be used only with a copper SFP and not supported with fiber SFP.
Follow these steps to connect M12 adapter to the SFP port:
Step 1 Insert the copper SFP in the chassis.
Step 2 Ensure the O-rings are on the M12 adapter and spacer.
O-ring2M12 adapter1
Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide
44
Installation Overview
Using M12 Adapter on SFP Port
