Grommet5Fiber SFP1
Ferrule6Fiber cable2
Clamp nut7O-Ring3
Adapter body4
Step 3 Plug the fiber cable into the SFP.
Step 4 Thread the adapter body (with O-Ring) into the chassis.
Step 5 Insert the grommet into the ferrule, and press it into the adapter body.
Step 6 Tighten the clamp nut onto the adapter body until the grommet compresses onto the fiber cable.
Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide
43
Installation Overview
Connecting to SFP Port Using Cable Gland
