DC power port connected using M12 adapter3SFP port connected using M12 adapter1

RJ45 port connected using M12 adapter2

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

Installation Overview

Using M12 Adapter on SFP Port
