Network Designer - Device Information
Device information including Device Model, Available Ports, and Slot Options will be displayed in the
Device Information Box which is located in the lower left had portion of the Network Designer, right
below the "Devices and Connectors" box.
This box will only refresh when you click on a specific Device under the “Devices and Connectors” on
the left-hand side of the program. .It’s primarily used for showing you stats of the Device BEFORE you
add them to your NetMap Topology.
The information for the device selected will be presented automatically.
