Cisco CGS 2520 Hardware Installation Guide
OL-31444-01
Chapter 1 Product Overview
Power Supply Side
Figure 1-7 Switch with One Power Supply Module
Figure 1-8 Switch with Both Power Supply Modules
For a description of the PSU OK LED, see Table 1-4 on page 1-10.
1 LED panel Power supply slot 1 3 Power supply slot 2
2
1
3
207200
Cisco C onnected Grid
Sw itc h 2500 Series
PW R-RGD-LOW -DC
1 PSU OK LED
207230
1
1
Cisco C onnected Grid
Sw itc h 2500 Series
PW R-RGD-LOW -DC
PW R-RGD-LOW -DC
