3-2
Cisco CGS 2520 Hardware Installation Guide
OL-31444-01
Chapter 3 Power Supply Installation
Power Supply Module Installation
Figure 3-1 PWR-RGD-AC-DC Power Supply Module
Figure 3-2 PWR-RGD-LOW-DC Power Supply Module
For a description of the PSU OK LEDs, see the “Power Supply Module LEDs” section on page 1-10.
Power Supply Module Installation
Installation Guidelines, page 3-3
Installing a Power Supply Module, page 3-3
Wiring the Power Source, page 3-7
Removing the Power Supply Module, page 3-11
1 Power supply module 3 Captive screw
2 PSU OK LED
207215
1
2
3
1 Power supply module 3 Captive screw
2 PSU OK LED
207232
1
2
3
PWR-RGD-LOW-DC
