Cisco CGS 2520 User Manual

B-4
Cisco CGS 2520 Hardware Installation Guide
OL-31444-01
Appendix B Connector and Cable Specifications
Cables and Adapters
Cables and Adapters
• SFP Module Cables, page B-4
• Cable Pinouts, page B-6
• Console Port Adapter Pinouts, page B-8
SFP Module Cables
Each port must match the wave-length specifications on each end of the cable, and for reliable
communications, the cable must not exceed the allowable length. Copper 1000BASE-T SFP transceivers
use standard four twisted-pair, Category 5 (or greater) cable at lengths up to 328 feet (100 meters).
Note The maximum operating temperature of the switch varies depending on the type of SFP module that you
use. See Table 1-2 on page 1-6 for information on the supported temperature ranges.
Table B-1 Fiber-Optic SFP Module Port Cabling Specifications
Type of SFP
Module
Wavelength
(nanometers) Fiber Type
Core
Size/Cladding
Size (micron)
Modal
Bandwidth
(MHz/km)
1
Cable Distance
Industrial and Rugged SFPs
1000BASE-SX
(GLC-SX-MM-
RGD)
850 MMF 62.5/125
62.5/125
50/125
50/125
160
200
400
500
722 feet (220 m)
902 feet (275 m)
1640 feet (500
m)
1804 feet (550
m)
1000BASE-LX/
LH
(GLC-LX-SM-
RGD)
1310 SMF G.652
2
— 32,810 feet (10
km)
100BASE-LX
(GLC-FE-100L
X-RGD)
1310 SMF G.652
2
— 32,810 feet (10
km)
100BASE-FX
(GLC-FE-100F
X-RGD)
1310 MMF 50/125
62.5/125
500
500
6,562 feet (2
km)
6,562 feet (2
km)
1000BASE-ZX
(GLC-ZX-SM-
RGD)
1550 SMF G.652
2
— 43.4 to 62 miles
(70 to 100 km)
2
Commercial SFPs
1000BASE-BX
10-D
(GLC-BX-D)
1490 TX
1310 RX
SMF G.652
3
— 32,810 feet (10
km)
