Setup Menu
123
Menu Item
Description
Parameters
TTL (Time To Live)
This sets the hop limit of the
packet's lifespan.
0 to 255
DestAddr
Enter the unicast (valid host IP
only) or multicast destination
IP address.
Unicast: valid host IP
Multicast: IP in range of 224.0.0.0 to
239.0.0.0
Note: We do not recommend that you
use multicast IP addresses reserved
by the Internet Assigned Numbers
Authority (IANA).
UDPPort
This selects the destination port
number.
1 to 65534
Note: If you selected RTP for MOIP,
you must select an even destination
port number.
Note: We do not recommend that you
use destination UDP ports reserved
by the IANA.
SrcPort
This selects the source UDP
port number.
0 to 65535
Note: Set the SrcPort to 0 to use the
default source UDP port (49162).
Send SAP
This selects whether to send
Session Announcement
Protocol messages.
None or RFC2327
SAP Multicast
Address
This is the IP address where the
SAP announcements are sent, if
required.
We do not recommend that you
change the default IP address
(224.2.127.254).
SAP Port
This is the UDP port where the
SAP announcements are sent, if
required.
1 to 65534
Note: We do not recommend that you
change the default SAP port 9875.
SAP ID
Describes the SAP output
stream name source.
User String or SDT Channel
SAP User Str
Provides the SAP user string.
Up to 31 characters
FEC
Select the error protection
profile.
For more information, see
Configuring Forward Error
Correction Settings (on page
248).
1D - Requires generation of one FEC
protecting stream: columns.
2D - Requires generation of two FEC
protecting streams: columns and
rows.
None - Disables the error protection.
Note: For more information, see
SMPTE 2022-1-2007.
