5-18 Cisco 4000 Series Hardware Installation and Maintenance
Memory Replacement Procedures
Figure 5-12 Inserting Flash-Memory SIMMs
Caution
You will feel some resistance, but do not use excessive force on the SIMM and do not touch
the surface components to avoid damaging them.
Step 4 Check the alignment of each SIMM to make sure that it is straight and that the alignment
holes are lined up with the plastic socket guides.
If you have completed all memory upgrade procedures, proceed to the section “Replacing Network
Processor Modules” later in this chapter.
The socket guide posts insert
through the SIMM holes
(on both sides).
3.
The locking spring will
clip the front side of the SIMM
when it is fully installed
(on both sides).
4.
H2474
Polarization
notch
1. Insert the SIMM into the socket at an angle 45° from vertical.
The socket guide posts insert
through the SIMM holes
(on both sides).
3.
The locking spring will
clip the front side of the SIMM
when it is fully installed
(on both sides).
4.
Side view
2. Push the SIMM down and back.
2. Push the SIMM down and back.
1. Insert the SIMM into the socket at an angle 45° from vertical.
Top view
Front of the chassis
