Preparing for Installation 2-13

Network Connection Considerations

Figure 2-9 Dual-Port Ethernet Network Processor Module with AUI and 10BaseT

Connectors

Token Ring Connections

The dual-port Token Ring network processor module has two standard 9-pin connectors.

(See Figure 2-10.) The single-port Token Ring network processor module has one standard 9-pin

connector. (See Figure 2-11.)

Figure 2-10 Dual-Port Token Ring Module Network Connector

H1480a

10BaseT ports

Alignment

groove

Alignment

groove

10BASE-T

AUI

LNK

POL

AUI

LNK

POL

ETHERNET AUI

AUI ports

DB-15 female

PORT-0

PORT-1

LEDs

H1980

Alignment

groove

Alignment

groove

Token Ring

IN-RING A

IN-RING B

RING ARING B

DB-9 female

Token Ring port

DB-9 female

Token Ring port

16MBPS
