B-4 Cisco 4000 Series Hardware Installation and Maintenance
Virtual Configuration Register Settings
router# configure terminal
Enter configuration commands, one per line.
Edit with DELETE, CTRL/W, and CTRL/U; end with CTRL/Z
config-register 0x102
Ctrl-Z
router#
The server creates a default boot filename as part of the automatic configuration processes. To form
the boot filename, the server starts with cisco and links the octal equivalent of the boot field number,
a dash, and the processor-type name. Table B-3 lists the default boot filenames or actions for the
processor.
Note A boot system configuration command in the router configuration in NVRAM overrides the
default netboot filename.
Table B-3 Default Boot Filenames
Action/File Name Bit 3 Bit 2 Bit 1 Bit 0
bootstrap mode 0 0 0 0
ROM software 0 0 0 1
cisco2-4000
or cisco2-4500
0010
cisco3-4000
or cisco3-4500
0011
cisco4-4000
or cisco4-4500
0100
cisco5-4000
or cisco5-4500
0101
cisco6-4000
or cisco6-4500
0110
cisco7-4000
or cisco7-4500
0111
cisco10-4000
or cisco10-4500
1000
cisco11-4000
or cisco11-4500
1001
cisco12-4000
or cisco12-4500
1010
cisco13-4000
or cisco13-4500
1011
cisco14-4000
or cisco14-4500
1100
cisco15-4000
or cisco15-4500
1101
cisco16-4000
or cisco16-4500
1110
cisco17-4000
or cisco17-4500
1111
