Cisco EF4116

Index 3
INDEX
Symbols
$ command (toggle cache state) C-2
? command (available bootstrap commands) C-2
Numerics
10BaseT
connecting cables 3-4
port 2-13
A
activity indicators, network 4-4
alarm message 4-3
asynchronous console port
See console port
asynchronous transfer mode
See ATM
ATM
cabling 2-35
network processor module 2-34
autopolarity 4-5
AUX
See auxiliary port
auxiliary port
connections 2-9
location 2-7
pinouts A-2
RJ-45 connector caution 3-8, A-22
B
b command (boot) C-2
Basic Rate Interface
See BRI
boot command D-3
boot ROMs, replacing 5-19
booting
from Flash B-6
from the ROM monitor
Cisco 4000-M C-2
Cisco 4500-M D-3
Cisco 4700 D-3
bootstrap
clear memory contents C-2
stack trace, system software C-2
Break key (interrupt) C-1, D-1
BRI
distance limitations 2-30, 3-6
making connections to 3-6
network hazardous voltage warning 3-6
pinout 3-8, A-22
C
c command (continue) C-2
cable
10BaseT 2-10
assemblies A-2–A-21
ATM 2-35
BRI A-22
CE1 A-23
console port, pinout A-2
CT1 2-31, A-22
Ethernet transceiver 2-10
IEEE 802.3 AUI 2-10
mismatch 4-8
multimode fiber-optic 2-25
pinouts
CE1 A-24
console port A-2
CT1, null-modem A-23
CT1, straight-through A-23
EIA/TIA-232, dual-port A-4
EIA/TIA-232, four-port A-5
EIA/TIA-449, dual-port A-7
EIA/TIA-449, four-port A-8
EIA-530, dual-port A-16
EIA-530, four-port A-18
V.35, dual-port A-10
V.35, four-port A-11
X.21, dual-port A-14
X.21, four-port A-15
serial, preparing to connect 2-21
single-mode fiber optic 2-25
specifications A-1
Token Ring lobe 2-14
transceiver 2-11
cables
safety guidelines 2-3
ungrounded 2-3
uninsulated 2-3
caution, description xvii
CE1
cable A-23
network processor module 2-32
channel service unit/digital service unit
See CSU/DSU
chassis
connecting 2-7
dimensions 1-3
opening 5-1
rear view 2-8
