Installing the Router 3-21

Connecting Routers with a DC-Input Power Supply

Figure 3-15 DC-Input Power Supply Connections

Warning

After wiring the DC-input power supply, replace the terminal block cover and screw to

ensure user safety.

Step 4 Remove the tape from the circuit breaker switch handle and restore power by moving the

circuit breaker handle to the ON position.

Caution To avoid damaging the power supply when returning the chassis to the manufacturer (for

example, if a failure occurs), remove the power supply terminal block cover so that it will fit in the

shipping container.

This completes the procedure for wiring the DC-input power supply.

Terminal block cover Terminal block

Terminal block

Terminal block cover

H2275

Ground

Positive

Negative

Captive screw

On/Off

Grommet
