Switch Installation
Connecting to a Console Port (Optional)
Figure 6 Installing the Flash Memory Card in the Switch
2. Install or remove the card:
To install a card, slide it into the slot, and press it in until it clicks in place. The card is keyed so that you cannot insert
it the wrong way.
To remove the card, push it in until it releases for it to pop out. Place it in an antistatic bag to protect it from static
discharge.
3. After the card is installed, close the guard door and fasten the captive screw using a Phillips screwdriver to keep the
door in place.
Connecting to a Console Port (Optional)
You can also enter CLI commands through the console port. For more information about this process see Accessing the
CLI Through the Console Port, page 45.
Warning: If you connect or disconnect the console cable with power applied to the switch or any device on the
network, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that
power is removed or the area is nonhazardous before proceeding.
Statement 1080
1 Flash Memory Card Slot
