Cisco IE 4000 Hardware Installation Guide

45
Cisco Systems, Inc. www.cisco.com
Configuring the Switch with the CLI-Based
Setup Program
This appendix provides a command-line interface (CLI)-based setup procedure for a switch.
Before connecting the switch to a power source, review the safety warnings in Warnings, page 13
For installation procedures, see Switch Installation, page 13
Accessing the CLI Through the Console Port
You can enter Cisco IOS commands and parameters through the CLI. Use one of these options to access the CLI:
 RJ-45 Console Port, page 46
 USB Mini-Type B Console Port, page 47
Removing the USB Mini-Type B Console Port Cover
To remove the cover from the USB mini-type B console port:
1. Use a Phillips screwdriver to loosen the captive screw on the USB mini-type B console port cover. See Figure 21 on
page 46. Remove the screw and take off the cover.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
