Hazardous Location Installation Information
Hazardous Locations Standards
Hazardous Locations Standards
Hazardous location standards for the Cisco IE 4000 switches:
Environmental Ranges
Operating temperature –29 to 165°F (–34 to 74°C)
Storage temperature –40 to 185°F (–40 to 85°C)
Operating altitude Up to 13,000 ft (3962 m)
Storage altitude Up to 40,000 ft (12,192 m)
Thermal spacing 3.54 in. (90 mm) exposed side
4.13 in. (105 mm) top and bottom
Power Requirements
AC input voltages Range: 85–264 VAC at 47–63 Hz
Nominal: 115 VAC at 60 Hz or 230 VAC at 50 Hz
Maximum AC power input current 0.75 A @ 230 VAC and 50 Hz or
1.3 A @ 115 VAC and 60 Hz
DC input voltages Range: 88–375 VDC
Nominal: 125 VDC or 250 VDC
Maximum DC input current 0.75 A at 220 VDC or
1.25 A at 150 VDC
Physical Dimensions
Weight 1.4 lb (0.63 kg)
Dimensions (W x D x H) 2 x 4.62 x 5.81 in. (50.8 x 117.5 x 147.6 mm)
Note: Width includes the cosmetic end-caps. Height does not include the
panel mount brackets. Depth is the distance from the rail.
The following standards were used for the hazardous
locations approvals and certifications:
Les normes suivantes ont été appliquées pour les
approbations et les certifications dans le cadre
d'environnements dangereux :
ANSI/ASA 12.12.01-2013 ANSI/ASA 12.12.01-2013
CAN/CSA C22.2 No. 60079-0: 11 CAN/CSA C22.2 n° 60079-0 : 11
CAN/CSA C22.2 No. 60079-15:12 CAN/CSA C22.2 n° 60079-15 :12
CSA C22.2 No. 213-M1987 CSA C22.2 n° 213-M1987
EN 60079-0:2012+A11:2013 EN 60079-0:2012+A11:2013
EN 60079-15:2010 EN 60079-15:2010
IEC 60079-0 6th Edition IEC 60079-0, 6e édition
IEC 60079-15 4th Edition IEC 60079-15, 4e édition
UL 60079-0, 5th Ed, 2009-10-21 UL 60079-0, 5e éd., 21-10-2009
UL 60079-15, 3rd Ed, 2009-7-17 UL 60079-15, 3e éd., 17-07-2009
