While removing the fan module, keep your hands and fingers away from the spinning fan blades.
Let the fan blades completely stop before you remove the fan module. Statement 258
Note
To remove the existing fan module, follow these steps:
Step 1
On the fan module that you are removing, press the two sides of the fan module handle next to where it connects to the
fan module and pull on the handles enough to unseat it from its connectors.
Step 2
Holding the handle, pull the module out of the chassis.
Do not touch the electrical connectors on the back side of the module and prevent anything else from coming
into contact with and damaging the connectors.
Caution
Step 3
Insert a fan blank module as shown in Figure 17: Inserted Fan Blank Modules, on page 40 if you do not have a new
fan module.
Cisco MDS 9132T Fibre Channel Switch Hardware Installation Guide
41
Installing the Cisco MDS 9132T Switch
Installing and Removing Fan Modules

Cisco MDS 9132T Specifications

General

Airflow	Front-to-back
Product Type	Fibre Channel Switch
Rack-mountable	Yes
Manageable	Yes
Product Model	MDS 9132T
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Power Supply	AC
Data Transfer Rate	32 Gbps
Fibre Channel Standard	FC-FS-2, FC-GS-4, FC-SW-2
Humidity	5% to 93% (non-condensing)
Ports	32 x 32Gbps Fibre Channel
Form Factor	1U
Dimensions	1.72 x 17.3 x 19.2 in
Port Speed	32 Gbps
Weight	17.6 lbs (8 kg)
