If you purchased this product through a Cisco reseller, contact the reseller directly for technical support.
If you purchased this product directly from Cisco, contact Cisco Technical Support at this URL: http://
www.cisco.com/c/en/us/support/index.html.
Note
Console Port
The console port is an asynchronous RS-232 serial port with an RJ-45 connector. You can use the RJ-45 to
RJ-45 rollover cable and the RJ-45 to DB-9 female adapter or the RJ-45 to DB-25 female DTE adapter
(depending on your computer serial port) to connect the console port to a computer running terminal emulation
software.
Console Port Pinouts
The following table lists the pinouts for the console port on the Cisco MDS 9132T Switch.
Table 15: Console Port Pinouts
SignalPin
RTS1
1
DTR2
TxD3
GND4
GND5
RxD6
DSR7
CTS8
1. Pin 1 is connected internally to pin 8.
Connecting the Console Port to a Computer Using the DB-25 Adapter
You can use the RJ-45 to RJ-45 rollover cable and RJ-45 to DB-25 female DTE adapter (labeled “Terminal”)
to connect the console port to a computer running terminal emulation software. The following table lists the
pinouts for the console port, the RJ-45 to RJ-45 rollover cable, and the RJ-45 to DB-25 female DTE adapter.
Cisco MDS 9132T Fibre Channel Switch Hardware Installation Guide
66
Cable and Port Specifications
Console Port
