Removing and Installing Cables into SFP+ or QSFP+ Transceivers
To prevent damage to the fiber-optic cables, do not place more tension on them than the rated limit and do
not bend to a radius of less than 1 inch if there is no tension in the cable, or 2 inches if there is tension in the
cable.
Caution
Removing a Cable from an SFP+ or QSFP+ Transceiver
When pulling a cable from a transceiver, grip the body of the connector. Do not pull on the jacket sleeve,
because this can compromise the fiber-optic termination in the connector.
Caution
If the cable does not remove easily, ensure that any latch present on the cable has been released before
continuing.
Caution
To remove the cable, follow these steps:
Step 1 Attach an ESD-preventive wrist strap and follow its instructions for use.
Step 2 Press the release latch on the cable, grasp the connector near the connection point, and gently pull the connector from
the transceiver.
Step 3 Insert a dust plug into the cable end of the transceiver.
Step 4 Insert a dust plug onto the end of the cable.
Installing a Cable into an SFP+ or QSFP+ Transceiver
To prevent possible damage to the cable or transceiver, install the transceiver in the port before installing the
cable in the transceiver.
Caution
To install a cable into a transceiver, follow these steps:
Step 1 Attach an ESD-preventive wrist strap and follow its instructions for use.
Step 2 Remove the dust cover from the connector on the cable.
Step 3 Remove the dust cover from the cable end of the transceiver.
Step 4 Align the cable connector with the transceiver and insert the connector into the transceiver until it clicks into place (see
the following image for reference).
Cisco MDS 9700 Series Switches Hardware Installation Guide
111
Connecting the Cisco MDS 9700 Series Switches
Removing and Installing Cables into SFP+ or QSFP+ Transceivers
