The following table describes the LEDs for the 48-Port 16-Gbps Fiber Channel Switching Module.
DescriptionStatusLED
All diagnostics pass. The module is operational (normal initialization
sequence).
GreenStatus
One of the following occurs or occurred:
• The module is booting or running diagnostics (normal initialization
sequence).
• The inlet air temperature of the system has exceeded the maximum
system operating temperature limit (a minor environmental
warning). To ensure maximum product life, you should immediately
correct the environmental temperature and restore the system to
normal operation.
Orange
One of the following occurs:
• The diagnostic test failed. The module is not operational because
a fault occurred during the initialization sequence.
• The inlet air temperature of the system has exceeded the safe
operating temperature limits of the card (a major environmental
warning). The card has been shut down to prevent permanent
damage.
Red
The operator has activated this LED to identify this module in the chassis.
Blinking blueID
This module is not being identified.Off
Link is up.
Solid greenLink
Link is up (traffic on port).Intermittent
blinking green
SFP is not present or Admin is down.Solid orange
A fault condition exists.Blinking orange
The port is not active or the link is not connected.Off
SAN Extension Modules
The following section describes the Cisco MDS 9000 SAN extension modules.
Cisco MDS 24/10 port SAN Extension Module
The Cisco MDS 24/10 port SAN Extension Module provides a high performance, flexible, unified platform
for deploying enterprise class disaster recovery and business continuance SAN extension solutions. The MDS
24/10 port SAN Extension Module is supported on Cisco MDS 9700 Series Multilayer Director Switches.
With 24 line rate 2-, 4-, 8-, 10-, and 16-Gbps Fiber Channel ports and eight 1 and 10GE or two 40GE Fiber
Channel over IP (FCIP) ports, this module enables large and scalable deployment of SAN extension solutions.
Cisco MDS 9700 Series Switches Hardware Installation Guide
46
Product Overview
SAN Extension Modules
