Table 12: Cisco MDS 9700 Series 24-Port 40-Gbps FCoE Module LEDs
DescriptionStatusLED
All diagnostics pass. The module is operational (normal initialization
sequence).
GreenStatus
One of the following occurs or occurred:
• The module is booting or running diagnostics (normal initialization
sequence).
• The inlet air temperature of the system has exceeded the maximum
system operating temperature limit (a minor environmental
warning). To ensure maximum product life, you should immediately
correct the environmental temperature and restore the system to
normal operation.
Orange
One of the following occurs:
• The diagnostic test failed. The module is not operational because
a fault occurred during the initialization sequence.
• The inlet air temperature of the system has exceeded the safe
operating temperature limits of the card (a major environmental
warning). The card has been shut down to prevent permanent
damage.
Red
The operator has activated this LED to identify this module in the chassis.
Blinking blueID
This module is not being identified.Off
Link is up.
Solid greenLink
SFP is not present or Admin is down.Solid orange
A fault condition exists.Blinking Orange
The port is not active or the link is not connected.Off
Cisco MDS 48-Port 10-Gbps Fiber Channel over Ethernet Module
The Cisco MDS 48-Port 10-Gbps Fiber Channel over Ethernet module (DS-X9848-480K9) is designed for
the MDS 9700 Series Directors. These modules are hot-swappable and they support 10-Gigabit Fiber Channel
over Ethernet ports in SFP+ form factor.
The Cisco MDS 48-Port 10-Gbps Fiber Channel over Ethernet module delivers integrated Fiber Channel over
Ethernet (FCoE), simplifies the network infrastructure, and helps reduce costs. The FCoE module allows you
to extend the existing Fiber Channel SANs by using FCoE. The Cisco MDS 48-Port 10-Gigabit Fiber Channel
over Ethernet module supports connectivity to FCoE switching platforms and to FCoE targets. This module
also supports connectivity to FCoE initiators and targets that only send FCoE traffic.
The Cisco MDS 48-Port 10-Gbps Fiber Channel over Ethernet module has the MPC8572 processor and 2 GB
DDR3 SDRAM. The module delivers 720 million packets per second (MPPS) and is capable of 480-Gbps of
data throughput. This module can power down data path slices to save power when the attached ports are not
in use.
Cisco MDS 9700 Series Switches Hardware Installation Guide
50
Product Overview
Cisco MDS 48-Port 10-Gbps Fiber Channel over Ethernet Module
