• 3 fan modules
• 1 to 4, 8, or 16 power supplies depending on the Cisco MDS 9700 Series switch
• Grounding lug kit
• Mounting kit
• ESD wrist strap
• Cables and connectors
• Cable management frames
• Left and right side frames
• Top frame
• M4 x 12 mm flat-head Phillips screws (12)
• Front door (1)
• M3X8 mm pan-head screws (2)
• Front door kit optional
Step 2 Check for damage and report any discrepancies or damage to your customer service representative. Keep the following
information ready:
• Invoice number of shipper (see packing slip)
• Model and serial number of the damaged unit
• Description of damage
• Effect of damage on the installation
Required Equipments
You need the following items before beginning the installation:
• Number 1 and number 2 Phillips screwdrivers with torque capability
• 3/16-inch flat-blade screwdriver
• Tape measure and level
• ESD wrist strap or other grounding device
• Antistatic mat or antistatic foam
• Torque wrench and socket for the DC power supply lug nuts
• In addition to the grounding items provided in the accessory kit, you need the following items:
Cisco MDS 9700 Series Switches Hardware Installation Guide
77
Installing the Cisco MDS 9700 Series Switches
Required Equipments
