10 3c-0e-23-c5-53-d0 to 3c-0e-23-c5-53-d3 JAE180605X3
Mod Online Diag Status
--- ------------------
1 Pass
2 Pass
3 Pass
4 Pass
5 Pass
6 Pass
7 Pass
8 Pass
10 Pass
Xbar Ports Module-Type Model Status
--- ----- ----------------------------------- ------------------ ----------
1 0 Fabric Module 1 DS-X9710-FAB1 ok
2 0 Fabric Module 1 DS-X9710-FAB1 ok
3 0 Fabric Module 1 DS-X9710-FAB1 ok
4 0 Fabric Module 1 DS-X9710-FAB1 ok
5 0 Fabric Module 1 DS-X9710-FAB1 ok
6 0 Fabric Module 1 DS-X9710-FAB1 ok
Xbar Sw Hw
--- --------------- ------
1 NA 1.0
2 NA 1.0
3 NA 1.0
4 NA 1.0
5 NA 1.0
6 NA 1.0
Xbar MAC-Address(es) Serial-Num
--- -------------------------------------- ----------
1 NA JAE222305VS
2 NA JAE2217096X
3 NA JAE222305V5
4 NA JAE2217096L
5 NA JAE2217096J
6 NA JAE222305V8
To view the inventory information for modules from the Cisco DCNM Web UI, Choose Inventory > View > Modules.
The Modules window is displayed with a list of all the switches and its details for a selected scope.
For more information, see the Cisco DCNM SAN Management Configuration Guide.
What to do next
Migrate the Crossbar Fabric-1 Switching Modules to Crossbar Fabric-3 Switching Modules. For more
information, see the “Nondisruptive Migration from Crossbar Fabric-1 Switching Modules to Crossbar Fabric-3
Switching Modules” section.
Switch with Only Active Supervisor Module
To perform a nondisruptive migration from a Supervisor-1/Supervisor-1E Module to a Supervisor-4 Module
in a switch that has only the active supervisor module installed and there is no standby supervisor module, or
the standby module is not in the HA-standby state, follow these steps:
Cisco MDS 9700 Series Switches Hardware Installation Guide
131
Installing, Removing, and Verifying Field Replaceable Units
Switch with Only Active Supervisor Module
