Before you begin
In the following procedure, all show outputs, system messages, and image file names are displayed for the
Cisco MDS 9710 Multilayer Director Switch. The show outputs, system messages, and image file names will
vary based on the Cisco MDS 9700 Series Multilayer Director Switch selected.
Note
Step 1 Use the show module command to view the Active and Standby supervisor modules.
In the following system message, Supervisor-1 Module (DS-X97-SF1-K9) is listed as Supervisor Module-3.
Note
switch# show module
Mod Ports Module-Type Model Status
--- ----- ----------------------------------- ------------------ ----------
1 48 1/10 Gbps Ethernet Module DS-X9848-480K9 ok
2 48 2/4/8/10/16 Gbps Advanced FC Module DS-X9448-768K9 ok
3 24 40 Gbps FCoE Module DS-X9824-960K9 ok
4 48 4/8/16/32 Gbps Advanced FC Module DS-X9648-1536K9 ok
5 0 Supervisor Module-3 DS-X97-SF1-K9 active *
7 34 1/10/40G IPS,2/4/8/10/16G FC Module DS-X9334-K9 ok
8 48 4/8/16/32 Gbps Advanced FC Module DS-X9648-1536K9 ok
10 48 2/4/8/10/16 Gbps Advanced FC Module DS-X9448-768K9 ok
Mod Sw Hw
--- --------------- ------
1 8.4(1) 1.1
2 8.4(1) 1.3
3 8.4(1) 1.0
4 8.4(1) 1.0
5 8.4(1) 1.3
6 8.4(1) 1.1
7 8.4(1) 1.0
8 8.4(1) 1.0
10 8.4(1) 1.1
Mod MAC-Address(es) Serial-Num
--- -------------------------------------- ----------
1 84-78-ac-1b-3d-58 to 84-78-ac-1b-3d-8b JAF1718AAAD
2 f4-cf-e2-7c-cd-30 to f4-cf-e2-7c-cd-33 JAE1847038X
3 04-6c-9d-32-36-aa to 04-6c-9d-32-37-1b JAE19330ASN
4 00-76-86-bf-58-23 to 00-76-86-bf-58-57 JAE203901ZG
5 9c-57-ad-fd-0d-cb to 9c-57-ad-fd-0d-dd JAE194005JC
6 e8-ed-f3-e5-9a-4d to e8-ed-f3-e5-9a-5f JAE17440HVB
7 00-da-55-a2-25-00 to 00-da-55-a2-25-0f JAE195004XM
8 74-86-0b-33-c6-70 to 74-86-0b-33-c6-a4 JAE213101Q3
10 3c-0e-23-c5-53-d0 to 3c-0e-23-c5-53-d3 JAE180605X3
Mod Online Diag Status
--- ------------------
1 Pass
2 Pass
3 Pass
4 Pass
5 Pass
6 Pass
7 Pass
8 Pass
Cisco MDS 9700 Series Switches Hardware Installation Guide
132
Installing, Removing, and Verifying Field Replaceable Units
Switch with Only Active Supervisor Module
