Table 45: AC PSU Requirements for Grid Redundancy
Minimum PSUs Required
for Grid Redundancy
Configurations
4Up to 8 x Cisco MDS 48 Port 64-Gbps Fibre Channel Switching Modules
4Up to 8 x Cisco MDS 48 Port 32-Gbps Fibre Channel Switching Modules
6Any other supported module or a combination of supported modules:
• 48 Port 64-Gbps Fibre Channel Switching Module
• 48 Port 32-Gbps Fibre Channel Switching Module
• 24/10 port SAN Extension Module
• 24 Port 40-Gbps Fibre Channel over Ethernet Module
• 48 Port 16-Gbps Fibre Channel Switching Module
• 48 Port 10-Gbps Fibre Channel over Ethernet Module
AC Power Supply Requirements for Grid Redundancy of Cisco MDS 9718
Director
The following table lists the AC PSU Requirements for Grid Redundancy of Cisco MDS 9718 Director.
Table 46: AC PSU Requirements for Grid Redundancy
Minimum PSUs Required
for Grid Redundancy
Configurations
8Up to 16 x Cisco MDS 48 Port 64-Gbps Fibre Channel Switching Modules
8Up to 16 x Cisco MDS 48 Port 32-Gbps Fibre Channel Switching Modules
8Up to 12 x Cisco MDS 48 Port 32-Gbps Fibre Channel Switching Modules and
up to 4 x 24/10 port SAN Extension Module
12Any other supported module or a combination of supported modules:
• 48 Port 64-Gbps Fibre Channel Switching Module
• 48 Port 32-Gbps Fibre Channel Switching Module
• 24/10 port SAN Extension Module
• 24 Port 40-Gbps Fibre Channel over Ethernet Module
• 48 Port 16-Gbps Fibre Channel Switching Module
• 48 Port 10-Gbps Fibre Channel over Ethernet Module
Cisco MDS 9700 Series Switches Hardware Installation Guide
195
Technical Specifications
AC Power Supply Requirements for Grid Redundancy of Cisco MDS 9718 Director
