Cisco MDS 9700 Series User Manual

• Network services such as access control lists (ACLs) and quality of service (QoS)
• Smart zoning
• Power-on self-test (POST) and diagnostics
• Switched Port Analyzer (SPAN) and Remote Switched Port Analyzer (RSPAN)
The following figure shows the Cisco MDS 9700 Series Supervisor-1E Module.
Figure 8: Cisco MDS 9700 Series Supervisor-1E Module
Module retaining screw1
ID: locator LED2
Link: management port link status LED3
MGMT Ethernet: MGMT0 Ethernet out of band port4
ACT: management port packet activity LED5
Console Serial Port: module serial console port6
Eject Request: eject request button for USB1 device7
USB1: usb1 status LED8
USB1 USB port9
Slot0: slot0 status LED10
Eject Request: eject request button for a slot0 device11
Reset: module reset button12
Module lock release button13
Status: system diagnostic test status LED14
System: system environment status LED15
Active: supervisor redundancy status LED16
Cisco MDS 9700 Series Switches Hardware Installation Guide
26
Product Overview
Cisco MDS 9700 Series Supervisor-1E Module
