Cisco MDS 9700 Series User Manual

Figure 12: Cisco MDS 9706 Crossbar Fabric Switching Module
Crossbar fabric switching module LEDs3Locking lever1
Connector pins4Unlocking button2
The LEDs on the crossbar fabric switching modules indicate the status of the modules. The table below
describes the LEDs.
Cisco MDS 9700 Series Switches Hardware Installation Guide
39
Product Overview
Cisco MDS 9706 Director Crossbar Fabric Switching Modules
