Cisco MDS 9700 Series User Manual

Power supply switch1
Power module handle2
AC power connection3
Ejector lever4
Power cable retainer5
Input power module LED6
Output power module LED7
Fault power module LED8
ID power module LED9
Figure 23: 3000-W DC Power Supply
Power supply switch1
Negative terminals2
Positive terminals3
Power supply handle4
Power supply exhaust5
Ejector lever6
Power module LED – Input1 power module LED7
Power module LED – Input2 power module LED8
Power module LED – Output power module LED9
Fault power module LED10
Cisco MDS 9700 Series Switches Hardware Installation Guide
58
Product Overview
Power Supplies
